Hi guys,
the side skirt on the jimny has come off. A friend stepped on it while getting out and it has obviously fallen off before and replaced with dodgy panel pins.
I now have a small problem of finding a set of the correct plastic trim panel pins to attach it back. I tried a few I had but nothing was suitable.
Any ideas what the actual pins are called?
Any help would be greatly appreciated!
Thanks all.
Jimny bodykit panel pin help
Re: Jimny bodykit panel pin help
Trim clips, they are about £4 each!
I've replaced mine with self tapping screws!
I've replaced mine with self tapping screws!
2002 Jimny O2 Ragtop
Safari Snorkel, Freewheeling Hub Conversion
Diff Breathers, G/Box and T/Box Breathers, 2in Suspension Lift
HD Recovery Points and Winch Plate
Kuhmo KL71 MT / Goodyear Wrangler AT
Wessex 4X4 Reponse - WE411
wessex4x4response.org.uk
-
ROBBIE
- I spend far too much time on here
- Posts: 4555
- Joined: Tue Sep 09, 2008 6:32 pm
- Location: Dorset or stuck
Re: Jimny bodykit panel pin help
Self tappers the way to go
Sid James gone but never forgotten
Jimny 1.6 not as good as an SJ but still good
Jimny 1.6 not as good as an SJ but still good
-
Darrell
- Suzuki, will you marry me?
- Posts: 2989
- Joined: Wed Feb 23, 2011 7:54 pm
- Location: south oxfordshire
- Contact:
Re: Jimny bodykit panel pin help
Give number 16 a Google.
Readily available on fleabay and cheap.
Readily available on fleabay and cheap.
- Attachments
-
- hjkj.jpg (57.45 KiB) Viewed 5583 times
2005-GV 1600se, "Hell" What do I know!
Re: Jimny bodykit panel pin help
I tried 16 (part number 09409-07332), they are push pins. They attach the skirt on the underneath. The clips that push into the trim & sill are different from those. I think I may have the right one, found 10 on ebay & with some luck might work!
Will keep the thread updated as to how I do
Thanks for the input.
Will keep the thread updated as to how I do
Thanks for the input.
